GENERAL

This compact, 10-centimeter pop-up sprinkler comes with a pre-installed MP Rotator, which provides up to 30% water savings over traditional nozzles. Add that to a spray body with a reliable two-piece ratchet, durable cap, and large filter screen with double filtration, and you have a tough combination to beat.

FEATURES

• Model (plastic riser): 10 cm.
• Flow rate: 0.61 to 16.07 l/min.
• Adjustable arc and radius offer timely and accurate settings.
• Drain check valve (up to 2 m of elevation).
• Two-piece ratchet.
• Zero flow-by wiper seal.
• Patented double pop.
• Warranty period: 2 years.
• Nozzle choices: MP100090, MP200090, MP300090, MP1000360, MP2000360, and MP3000360.

OPERATING SPECIFICATIONS

• Flow rate: 0.61 to 16.07 l/min Radius: 2.5 to 9.1 m.
• Recommended pressure range: 1.7 to 3.8 bar; 170 to 380 kPa.
• Precipitation rates: 10 mm/hr approx.

FACTORY INSTALLED OPTIONS

• MP 1000 90-210 degrees, 360°.
• MP 2000 90-210 degrees, 360°.
• MP 3000 90-210 degrees, 360°.

USER INSTALLED OPTIONS

• Drain check valve: 10 cm model (up to 2 m of elevation; P/N 462237).
• Other MP Rotator models.
